Description
1. DISPLAY FEATURES
Panel Size 43″ Aspect Ratio 16:9
Resolution 1920*1080 Brightness 210±20 cd/m²
Contrast 1200:1 (Typ.) Viewing angle 89/89/89/89（Typ.）（CR≥10）
Response time 10 ms Maximum Colors 16.7M (8-bit)
2. PORT CONFIGURATION
ATV × 1
DVB-T/C/T2 /S/S2 × 1
HDMI ×2 AV IN × 1 Support PAL/NTSC
USB ×2 2.0USB EAPPHONE × 1 130 ~ 150mVRMS
RJ45 ×1 COAX × 1
3.ANDROID CONFIGURATION
CPU 4 Cores A53 1GHz eMMC FLASH 8G Byte
CPU Frequency 850MHz DDR SIZE 1G Byte
3.1. PRE-INSTALLED APP
Google Play YES Facebook YES
Miracast YES Spotify YES
YouTube YES chrome YES
Netflix YES
zoom ratio YES 4:3,16:9,zoom1,zoom2
sleep settings YES off,15Min,30Min,45Min,60Min,90Min,120Min
Teletext YES Europan
HDMI CEC YES CEC，*ARC(HDMI1)
4.TV RECEPTION SYSTEM
ATV System TV System
Supportable video format B、SECAM Digital video decode –
5.SOUND SYSTEM
ATV sound system Max.Audio output power 2*8W@8Ω 8Ω10W speaker
Sound Mode Standard; music; movie; news; user Equalizer YES
6.POWER REQUIREMENTS
Input Voltage 100-240V AC 50/60HZ Power ON consumption ≦78W
Standby consumption 〈0.5W
7.USB
Audio support format MP3,PCM,AAC etc. Picture support format JPEG,BMP,PNG,JPG
Video support format avi 、mp4 、mpg 、mkv 、mov 、vob 、rm 、rmvb etc.
8.HDMI/AV
HDMI Video support format 480i, 480p, 720p, 1080i, 1080p AV Resolution 480i, 480p, 720p, 1080i, 1080p
9.ACCESSORIES IN THE BOX
User Manual YES Wall mount Optional
Remote Control YES Mini AV cable Optional
Remote Batteries Optional Mini YPbPr cable NO
Stand YES Mini YPbPr cable NO
10. OSD LANGUAGE
English, French, German, Russian, Spanish, Portuguese, etc.
11.Packing details
DIMENSION WEIGHT（Parts are inconsistent, the weight will have a large ± tolerance）
Unit(mm) 1Pc/1Carton(mm) Net(Kg) 1Carton(Kg)
» with Stand:
954.9*211.6*617.5 ;
W/O Stand: No bracket size 954.9*83.3*564.1″ 992*102*598 5.70 6.80
